Parts List
Item Part Number Description Qty
1 90038-001 Beam 1
2 90038-002 Bolt M12x55 12
3 90038-003 Flat Washer ø12 20
4 90038-004 Nut M12 12
5 90038-005 Wedge Slide 1
6 90038-006 Spacer 2
7 90038-007 Plate 2
8 90038-008 Lock Washer ø24 4
9 90038-009 Flat Washer ø24 4
10 90038-010 Nut M24 4
11 90038-011 Axle, Outer Bushing 2
12 90038-012 Axle Cover 2
13 90038-013 Hydraulic Hose (Valve, Pump) 1
14 90038-014 Log Splitter Control Valve 1
15 90038-015 Hydraulic Hose (Valve, Oil Tank) 1
16 90038-016 Valve Handle 1
17 90038-017 Pin 5x25 1
18 90038-018 Split Pin 2x10 3
19 90038-019 Pin 5x16 1
20 90038-020 Valve A-Joiner 1
21 90038-021 Combination Washer ø14 4
22 90038-022 Bolt Connector 2
23 90038-023 Hydraulic Hose (Valve, Cylinder) 1
24 90038-024 Cylinder 1
25 90038-025 Flat Washer ø20 1
26 90038-026 R-Pin 3x55 2
27 90038-027 Spring 1
28 90038-028 2" Coupler 1
29 90038-029 Hitch Pin 1
30 90038-030 Tow Bar 1
31 90038-031 Bolt M12x40 4
32 90038-032 Hex Lock Nut M10 12
33 90038-033 Lock Washer ø10 10
34 90038-034 Rear Support Leg 1
35 90038-035 Hitch Pin 1
36 90038-036 Bolt M10x75 2
37 90038-037 Hinge Pin 1
38 90038-038 Breather Cap 1
39 90038-039 Oil Tank 1
40 90038-040 Bolt M12x90 1
41 90038-041 Safety Chain with Hook 2
42 90038-042 Pin 1
43 90038-043 Bolt M12x80 2
44 90038-044 Bolt M8x20 4
45 90038-045 Flat Washer ø8 15
46 90038-046 Lock Washer ø8 12
47 90038-047 Gear Pump 1
48 90038-048 Bolt M10x60 4
49 90038-049 Split Pin 4x40 1
50 90038-050 Composite Bearing 4
51 90038-051 Wheel / Tire Assembly 2
52 90038-052 Split Pin 4x30 2
