Syn-Tech III P25 Mobile Radio
OPERATION MANUAL
680-090-2041
Version 5.0
http://www.midlandradio.com
53
5 STATUS
51 PRESENT STATUS – View and set present status
54 RECEIVED STATUS – View last ten received status messages
53 STATUS REQUEST – Request another radio’s present status
note 5
52 SEND STATUS – Send present status to another radio
note 5
4 PREDEFINED MESSAGES
41 RECEIVED MESSAGES – View last ten received messages
43 MESSAGE LIST – View and send predefined message
note
4
42 SENT MESSAGES – View last ten sent messages
note
4
6 RADIO INFO
61 IDENTS
SERIAL NO – View electronic serial number
WACN – View wide area communication network ID
IDENT – View digital unit ID
ANI, SC, ACK – View analog IDs
65 MEASUREMENT
651 RSSI – Measure receive signal strength
653 POWER SUPPLY – Measure supply voltage
652 GPS – View present GPS data
64 BATTERY INFO (portable only) (for OEM rechargeable batteries)
CHARGE, COUNT – View remaining battery capacity & charge cycle count
TYPE – View battery type
VOLT, CURR, TEMP – View batter voltage, current and temperature
TERMINAL IP-ID – View IP address
RADIO NAME
SYSTEM NO – View system ID
63 HARDWARE
UNIT, RF CARD, FRONT – View PCB assembly versions
DSP, ENCRYPT, BAND – View PCB assemly & encryption versions & band
62 SOFTWARE
VERSION – View microcontroller flash version
DSP VERSION – View DSP flash version
