Front Panel and Remote Control Functions for the KID
22 iPod-device docking station
Connect the iPod-device to the KID by plug-
ging it into the dock connector. The iPod-
device takes the KID in and out of stand-by.
When an iPod-device is connected to the dock
connector, the KID automatically moves to the
operational mode from stand-by.
When an iPod-device is removed from the
dock connector, the KID automatically reverts
to the stand-by mode.
23 Aux Input
Use this input instead of the dock connector to
connect any audio source via a 3.5 mm stereo
phone cable.
TOP AND FRONT PANEL ONLY
28 DISP Key
T
ur
ns on the iPod-device backlight.
29 Menu Key
Activates the iPod-device menu function. The
r
emote menu key does not have a held function.
30 Up Directional Key
Performs the iPod-device up arrow function.
31 Down Directional Key
Performs the iPod-device down arrow function.
32
Left and Right Directional Keys
or T
rack Keys
Activate the iPod-device previous and next
track functions r
espectively
.
33 Play Key
Performs the iPod-device play/r
esume function.
34 Stop Key
Performs the iPod-device stop function.
35 Repeat Key
Per
for
ms the iPod-device r
epeat function.
36 Shuffle Button
Performs the iPod-device shuffle function.
37 Pause Key
Performs the iPod-device pause function.
38 Mute Key
Performs the iPod-device mute function.
39 Search Up/Down Keys
Pr
ess and hold these keys to perform the
iPod-device sear
ch function.
40 Album Up/Down Keys
Perform the iPod-device album up and down
functions.
41 Playlist Up/Down Keys
Per
form the iPod-device playlist up and down
functions.
REMOTE ONLY
24 Power Button
Press the power button or key to take the KID
in and out of stand-by.
Power LED Color Guide
When the KID is plugged into AC power, the
power LED illuminates:
Red The KID is in stand-by mode.
Blue The KID is on, in the operational mode,
indicating that an iPod-device is con-
nected.
Purple The KID is on, in the operational mode,
and an iPod-device is not connected.
25 Bass Control
Two buttons or keys control the bass tone
control + or - 6 dB. The bass control is within
the KID and not in the iPod-device.
26 Treble Control
Two buttons or keys control the treble tone
control + or - 6 dB. The treble control is within
the KID and not in the iPod-device.
27 Volume Control
The iPod-device volume control is not active
when the iPod-device is connected to the KID.
Two up or down buttons on the KID, or the
two up or down keys on the KID remote, con-
trol the volume, from 0 to 151. Press and hold
both volume buttons or keys at the same time
for 3 seconds. The volume locks, and the KID
can be used as a source in an A/V system.
Press and hold both volume buttons or keys at
the same time, for 3 seconds, to unlock the
volume.
FRONT PANEL AND REMOTE
