6 VS735
The [POWER] button turns the VS735 on and off. When the
ignition switch is in the ACC or RUN positions, this button is
illuminated red. The [POWER] button on the remote can also
be used.
The IR Receiver detects the signals from the included infrared
remote control. Aim the remote control at the IR receiver
during use.
DVD
VCD
CD
DOLBY
DIGITAL
REMAIN
ANGLE
CHP
TRK
A -
B
REPEAT 1
TITLE
SCN
RDM
L
/
R
MP
3
PBC
Media Type
Play/Pause
Disc
Status
Disc Loaded
Alphanumeric display
Function
status indicators
Playback Control Status
Mono Audio
Indicator
The front-panel display provides basic information about the
status of the VS735. Please note that much information about
using the VS735 will be displayed on the video screen
connected to the unit, and initial setup of the VS735 cannot be
completed without an operating video monitor providing this
on-screen display of menus and settings. Whenever the term
“on-screen display” is used, it refers to the video monitor
display, not the front panel display.
Disc loading
slot
Eject button
(on back of DCP)
Reset button
Security
LED
DCP release button
(on back of DCP)
Once the face is lowered, insert discs by placing them into
the disc loading slot.
The [ ] eject button is located on the back of the detachable
control panel (DCP), not on the front panel. It is backlit green
whenever the key is in the ACC or RUN positions. It ejects
discs from the disc loading slot.
The Security LED flashes red when the Detachable Control
Panel is removed.
The Reset button can be used to reset the internal micropro-
cessor. See “Troubleshooting”, in Section 10, for more
information.
