8
Listening To External Sound sources
If you have an external audio source you always want
to keep connected to the SoundWorks Radio CD, like
a desktop cassette player, connect it to the AUX input
on the rear panel (See P). Press the AUX button on the
front panel or remote control to select this input
(See Q).
If you have an external audio program source you
occasionally want to connect to the Radio CD, like a
portable MP3 player, connect it to the AUX-F input on
the front panel (See Q). This input overrides the rear
AUX input. The AUX button on the front panel or
remote control selects this input (See R).
Mixing Input/Record Output
You may want to mix the sound from an audio program
source (computer audio output, for instance) with the
other Radio CD audio sources (FM, AM, Disc, Aux).
Connect the audio source to the MIXING INPUT on the
rear panel (See S). The program source will be mixed
with the currently selected Radio CD program source.
The audio source connected to the Mixing Input must
have a level control if you wish to adjust the balance
between the Radio CD program source and the Mixing
Input audio source.
CONNECTING AN EXTERNAL AUDIO SOURCE
FM 1/2
CD INFO
CD MODE REPEAT
PRESETS
FOLDER
VOLUME
JOG
AM AUX
POWER
TRACK
SEEK
CD
/TUNE
WIDE
STEREO
MONO
1234
5678
AUX-F
HEADPHONES
FM2 P1
88 . 1
9 : 43AM
PRESETS
ALARMS
TAP TO SET
PRESS & HOLD TO ADJUST
1
2
SOUNDWORKS RADIO
TUNE
WAKEUP
TIME
ADJUST
FM1/2
AM
SEEK
AUX
AUX
F
JOG
VOLUME
SLEEP
SNOOZE
MUTE
1
2
3
4
5
6
7
8
POWER
+
FM 1/2
CD INFO
CD MODE REPEAT
PRESETS
FOLDER
VOLUME
JOG
AM AUX
POWER
TRACK
SEEK
CD
/TUNE
WIDE
STEREO
CD IN
MONO
FM2 P1
88 . 1
1234
5678
9:43AM
MIXING
INPUT
RECORD
OUTPUT
INPUT INPUT
AM
ANTENNA
FM ANTENNA
EXT
INT
INPUT
75 OHMS
AUX
MIXING
INPUT
RECORD
OUTPUT
INPUT INPUT
AM
ANTENNA
FM ANTENNA
EXT
INT
INPUT
75 OHMS
AUX
P.
Q.
R.
S.
