Setting the Clock
You can adjust the current time whether the radio is
in Standby or On. Just press the time adjust buttons
(next to the symbol) on the right hand side of the
display (See E).
Note: The current time can only be adjusted from the
Radio CD faceplate. The Remote Control can adjust
the wake up time setting, but not the current time.
Tone Alarm Backup Battery
For 48 hours of alarm function backup during an AC
power failure, obtain and install a 9 volt battery in the
radio compartment. Release the battery cover, attach
the battery and restore the cover.
If either alarm is set to activate (music or tone wake-
up) and the power fails, the battery sounds the
tone
alarm at the appropriate time. Press Power on the
radio to silence the alarm. Remove the battery if the
unit is unplugged for more than 24 hours. Replace the
battery after 30 minutes of emergency tone alarm
operation (See F).
Standby and On
Pushing the POWER button chooses Standby or On
operation (See G)
The faceplate Power button can also be used to
engage SLEEP delay operation (See page 8).
Selecting The Radio Bands
1) Pressing the FM 1/2 button selects the FM radio
band and one of two banks of FM station presets.
You can store eight FM stations in the PRESET
bank FM1 and eight different FM stations in
PRESET bank FM2 (See H).
2) If you switch from another mode to FM, the Radio
will return to the last PRESET bank used (from
Standby, AM, CD or from an AUX input). Pressing
the FM 1/2 button during FM operation selects the
other preset bank.
3) Pressing the AM button selects the AM radio band.
The AM band has one PRESET bank.
GETTING STARTED
G.
H.
PRESETS
ALARMS
TAP TO SET
PRESS & HOLD TO ADJUST
FOLDER
REPEAT
+
1
2
SOUNDWORKS RADIO CD
SEEK
STOP
TRACK / TUNE
WAKEUP
TIME
ADJUST
CD
FM1/2
AM AUX
JOG
VOLUME
SLEEP
SNOOZE
MUTE
1
2
3
4
5
6
7
8
CD MODE
CD TIME
POWER
FM 1/2
CD INFO
CD MODE REPEAT
PRESETS
FOLDER
VOLUME
JOG
AM AUX
POWER
TRACK
SEEK
CD
/TUNE
WIDE
STEREO
CD IN
MONO
1234
5678
9:43AM
PRESETS
ALARMS
TAP TO SET
PRESS & HOLD TO ADJUST
FOLDER
REPEAT
+
1
2
SOUNDWORKS RADIO CD
SEEK
STOP
TRACK
/
TUNE
WAKEUP
TIME
ADJUST
CD
FM1/2
AM AUX
JOG
VOLUME
SLEEP
SNOOZE
MUTE
1
2
3
4
5
6
7
8
CD MODE
CD TIME
POWER
FM 1/2
CD INFO
CD MODE REPEAT
PRESETS
FOLDER
VOLUME
JOG
AM AUX
POWER
TRACK
SEEK
CD
/TUNE
WIDE
STEREO
CD IN
MONO
1234
5678
FM2 P1
88 . 1
9:43AM
FM 1/2
CD INFO
CD MODE REPEAT
PRESETS
FOLDER
VOLUME
JOG
AM AUX
POWER
TRACK
SEEK
CD
/TUNE
WIDE
STEREO
CD IN
MONO
CURRENT TIME
7:43 AM
1234
5678
E.
F.
