11
10
WIDE
STEREO
MONO
HEADPHONES AUX-F
INDICATES DISC INSIDE
EJECTS DISC
TAP TO ACTIVATE ALARM
PRESS AND HOLD TO ADJUST ALARM
DURING DISC PLAY, TAP THIS BUTTON FOR:
AUDIO CD:
TRACK TIME ELAPSED, TRACK TIME REMAINING
TOTAL TIME ELAPSED, TOTAL TIME REMAINING
CD-ROM:
TRACK TIME ELAPSED
DURING DISC PLAY, TAP THIS BUTTON FOR:
AUDIO CD:
RANDOM PLAY, PLAY ONE TRACK
CD-ROM:
RANDOM PLAY OF DISC, PLAY ONE FOLDER
RANDOM PLAY OF ONE FOLDER , PLAY ONE TRACK
RADIO STATION PRESET BUTTONS:
PRESS AND HOLD TO STORE CURRENT STATION
INDICATES ALARM STATUS
= MUSIC WAKEUP
= TONE WAKEUP
INSERT HEADPHONES WITH 3.5mm STEREO MINIPLUG HERE FOR PRIVATE LISTENING
INSERT AUDIO PLAYER WITH 3.5mm STEREO MINIPLUG HERE. PRESS AUX TO HEAR IT:
THIS INPUT OVERIDES AUX-R IN BACK.
ADJUSTS VOLUME DURING NORMAL OPERATION: ADJUSTS SETTINGS IN JOG BUTTON OPERATION.
SELECTS FM BAND
PRESS AGAIN TO SWITCH BETWEEN PRESET BANK 1 OR 2
PRESS REPEATEDLY TO VIEW MANY RADIO SETTINGS.
USE VOLUME TO ADJUST SETTINGS.
BASS
_
+4 TO -4 SNOOZE TIME- 5 MIN TO 22 MIN
TREBLE
_
+4 TO -4 RDS TEXT- SCROLLING, FIXED, OFF
STEREO, WIDE, MONO DISC TEXT- SCROLLING, FIXED, OFF
LOUDNESS- ON, OFF TIME DISPLAY- 12 hr AM/PM OR 24 hr
DISPLAY LANGUAGE- ENGLISH, SPANISH, FRENCH,
ITALIAN OR GERMAN
SELECTS AM BAND
(ONE PRESET BANK)
SELECTS AUX INPUT
SELECTS RADIO "ON" OR "OFF"
(ALARMS ACTIVE IN "OFF" MODE)
PRESS REPEATEDLY FOR SLEEP DELAY
FUNCTION (15 MIN TO 120 MIN)
RADIO: TAP TO MANUAL TUNE, PRESS AND
HOLD TO SEEK NEXT STATION.
DISC: TAP TO ADVANCE OR GO BACK ONE AUDIO
SELECTION, PRESS AND HOLD TO SCAN
FORWARD OR BACKWARD THROUGH AN AUDIO.
RADIO: TAP TO AUTOMATICALLY SEEK
THE NEXT STATION UP THE BAND.
DISC: TAP TO STOP PLAY.
TAP TO START DISC PLAY, TAP
AGAIN TO PAUSE DISC PLAYBACK.
DURING DISC PLAY, TAP THIS BUTTON FOR
REPEAT PLAY OF CURRENT CD MODE
TAP THESE BUTTONS TO MOVE BETWEEN
DIFFERENT DIRECTORIES ON A CD-ROM DISC
SETS CURRENT TIME
IN NORMAL OPERATION
SETS WAKEUP TIME IN ALARM
ADJUSTMENT MODE
INDICATES AUDIO MODE
NORMAL OPERATION: PRESS TO MUTE SOUND.
DURING WAKEUP: PRESS TO TO ACTIVATE SNOOZE FEATURE.
FM ANTENNAAM
ANTENNA
INPUT
MIXING
INPUT
RECORD
OUTPUT
AUX
INPUT
EXT
INT
75 OHMS
REAR 3.5mm STEREO
MINIJACK AUXILIARY INPUT
AM ANTENNA
INPUT MINIJACK
EXTERNAL FM ANTENNA
"F" TYPE INPUT
3.5mm STEREO MINIJACK FIXED LEVEL AUDIO
OUTPUT ALSO FUNCTIONS AS A MIXING INPUT
INTERNAL / EXTERNAL
FM ANTENNA SELECTOR
SOUNDWORKS RADIO CD
FRONT AND TOP PANEL
FUNCTIONS
QUICK REFERENCE GUIDE - SOUNDWORKS RADIO CD FACEPLATE
