16-EN
SETUP
You can flexibly customize the unit to suit your own preferences and
usage. From the SETUP menu, choose from Sound Customizing,
Visual Customizing, etc., to make your desired settings.
CDE-9846
CDE-9842
A typical SETUP procedure is shown in steps 1 to 4
as follows. See below for further information about
each SETUP menu.
1
Press and hold MUTE/SETUP for at least 2
seconds.
SETUP mode is activated.
2
Press g or f to select the desired SETUP
menu.
(e.g. Select SUBW)
CDE-9846
DIM → SUBW → CD-DA / CDDA/MP3 → SCR TYPE → SCR →
PWR → AREA
* → DIM
* Refer to “Changing the Radio Frequencies for each Country”
(page 6).
CDE-9842
SUBW → PWR → SUBW
3
Press BAND to change the setting.
(e.g. Select SUBW ON or SUBW OFF.)
4
Press MUTE/SETUP for at least 2 seconds again.
The display returns to normal mode.
Sound Customizing
Subwoofer On and Off
SUBW ON (Initial setting) / SUBW OFF
When the subwoofer is on, perform the steps below to adjust the
subwoofer output level.
1Press the Rotary encoder (CDE-9846 only) or press
MODE (CDE-9842 only) repeatedly to select the
SUBW mode.
BASS LV → TRE LV → SUBW* → BALANCE → FADER →
DEFT → VOLUME → BASS LV
2To adjust the level, turn the Rotary encoder (CDE-9846
only) or press 4 and 3 (CDE-9842 only).
* When the subwoofer mode is set to OFF, its level cannot be
adjusted.
Visual Customizing (CDE-9846 only)
Dimmer Control (CDE-9846 only)
CDE-9846:
DIM AUTO (Initial setting) / DIM MANU
Set the DIM control to AUTO to decrease the illumination brightness
of the unit with the head lights of the vehicle ON. This mode is useful
if you feel the unit's button lighting is too bright at night.
Scroll Type Setting (CDE-9846 only)
TYPE1 (Initial setting) / TYPE2
Choose from two scrolling methods.
Select the type you prefer.
Scroll Setting (CDE-9846 only)
CDE-9846:
SCR AUTO / SCR MANU (Initial setting)
This CD player can scroll the disc and track names recorded on CD-
TEXT discs, as well as the text information of MP3 files, folder
names, and tags.
SCR AUTO : The CD text information, the text information
of folder and file names, and the tags are
scrolled automatically.
SCR MANU : The display is scrolled only when a disc is
loaded or when a track is changed, etc.
• The unit scrolls CD text names, folder names, file names or tag
display. The disc titles input manually (page 15) cannot be scrolled.
g f
BAND
g f
BAND
MUTE/SETUP
MUTE/SETUP
4
MODE
Rotary encoder
3
