Listening to the radio
These are the basic steps necessary to operate
the radio. More advanced tuner operation is
explained starting on the next page.
Important
If you are usingthis unit in North,Central or
South America, resetthe AM tuning step(see
Setting the AMtuning step on page 28).
1 Bandindicator
Shows which band the radio is tuned to, AM
or FM.
2 Frequencyindicator
Shows the frequency to which the tuner is
tuned.
3 Stereo(5) indicator
Shows when the selected frequency is
being broadcast in stereo.
4 Presetnumber indicator
Shows which preset has been selected.
1 Press SOURCE to select the tuner.
Press SOURCE until you see TUNER dis-
played.
2 Use VOLUME to adjust the sound level.
Rotate it to increase or decrease the volume.
3 Press BAND to select a band.
Press BAND until the desired band (F1, F2, F3
for FM or AM) is displayed.
4 To perform manual tuning, briefly press
c or d.
The frequencies move up or down step by
step.
5 To perform seek tuning, press and hold
c or d for about one second and release.
The tuner will scan the frequencies until a
broadcast strong enough for good reception is
found.
# You cancancel seek tuning bybriefly pressing
c or d.
# If you press andhold c or dyou can skip sta-
tions. Seek tuningstarts as soon asyou release
the button.
