Memory Locations and Replacement Procedures
B-4 Mode Switch Bank Settings and Optional Installations
Installing the DIMM
ToinstallaDIMM,refertoFigure B4andproceedasfollows:
1. InserttheDIMMdownbetweentheconnectorfingers.
2. PivottheDIMMdownwardsothetabsontheconnectorarmsalignwiththetwoDIMM
alignmentnotches.Withthetwoconnectorarmsspreadoutward,pushtheDIMMdown
betweentheconnector
arms.ThenreleasethetwoconnectorarmstolocktheDIMMinto
place.
Figure B-4 Installing the DIMM
Caution: Observe all Electrostatic Discharge (ESD) precautions when handling sensitive electronic
equipment.
Precaución: Al trabajar con equipos electrónicos sensibles, tome todas las precauciones de
seguridad para evitar descargas de electricidad estática.
1 DIMM 3 Connector arms
2 Connector fingers 4 DIMM alignment notches (2)
