Engine Parts List
# Part Number Description Qty
1
ST160F-1061200 Knob, Recoil Assembly 1
2
GB5789-FB6-8 Flange bolt M6x8 3
3
188.061100.31 Case, Recoil Assembly 1
4
ST188F-1060009 Return Spring, Recoil Assembly 1
5
ST188F-1060008 Pulley, Recoil Assembly 1
6
ST188F-1060007 Rope, Recoil Assembly 1
7
ST188F-1060006 Ratchet Spring 2
8
ST188F-1060005 Starter Ratchet 2
9
ST188F-1060004 Spring, Ratchet Guide 1
10
ST188F-1060003 Ratchet Guide 1
11
ST188F-1060002 Bolt, Ratchet Guide 1
12
GB5789-FB6-12 Flange Bolt M6x12 13
13
ST188F-1080003 Clamp 1
14
ST188F-1080100-G Fan Cover 1
15
ST188F-1050006 Flywheel Nut 1
16
GB5789-FB6-29 Flange Bolt 6x29 2
17
ST188F-1060001 Start Hub 1
18
ST188F-1122000-G Ignition Coil 1
19
ST188F-1080002 Fan－Engine 1
20
ST188F-1121000 Flywheel 1
21
ST188F-1030200 Oil Seal 2
22
168.120700.00 Three-Way Wire 1
23
ST160F-1126000 Diode 1
24
ST188F-1030012 Sheath－Wire 1
25
139FMD-1003101 Drain Bolt 2
26
139FMD-1003102 Washer, Drain bolt 2
27
ST182F-1030006-G Crankcase Assembly 1
28
ST188F-1127000-A Oil Level Sensor 1
29
GB5789-FB6-15 Flange Bolt 6x15 2
30
GB276-BB-6202-SS Radial Ball Bearing 6202/P6 2
31
ST188F-1050303 Balance gear 1
32
GB276-BB-6207-UU Radial Ball Bearing 6207/C3 2
33
ST188F-1050304 Key 1
34
ST188F-1050300-Q Crankshaft Assembly 1
35
ST188F-1030010-G Gasket, Crankcase 1
36
ST168F-1030015-G Dowel Pin 9x14 2
37
ST188F-1080002-G Air Guide Board 1
38
ST188F-1030003-B Oil filler Cap 1
39
ST160F-1030002 Oil Filler Cap Packing 2
40
ST188F-1030011-G Cover, Crankcase 5/16-24UNF 1
41
ST188F-1030003 Oil Dipstick 1
42
GB5789-FB8-40 Flange Bolt 8x40 7
43
ST160F-1110108 Washer 1
44
ST188F-1110009 Shaft, Govorner Gear 1
45
ST188F-1110101 Governor Gear 1
46
ST188F-1110102 Pin, Governor Weight 3
47
ST188F-1110103 Governor Weight 3
48
ST160F-1110103 Clip, Governor Gear 1
49
ST188F-1110008 Bushing, Governor Gear 1
50
ST188F-1050200 Connecting Rod Assembly 1
51
ST182F-1050001 Piston 1
52
ST188F-1050004 Clip, Piston Pin 2
53
ST188F-1050005 Piston Pin 1
54
ST182F-1050100 Ring, Oil 1
55
ST182F-1050003 Ring, Second Piston 1
56
ST182F-1050002 Ring, First Piston 1
57
ST188F-1030013 Dowel Pin 2
58
ST188F-1030008-G Gasket, Cylinder Head 1
59
ST188F-1080001-G Shroud 1
60
ST188F-1011000-G Cylinder Head Assembly 1
61
F6RTC Spark Plug 1
62
ST188F-1030009 Bolt 4
63
ST188F-1020003-CPE Gasket, Valve Cover 1
64
ST188F-1020100-A Valve Cover 1
65
ST188F-1020002 Tube 1
66
ST188F-1020004 Gasket, Bolt 1
67
ST188F-1020005 Washer, Valve Cover 1
68
ST188F-1020006 Bolt, Valve Cover 1
69
ST188F-1041000 Camshaft Assembly 1
70
ST188F-1040012 Valve Lifter 2
71
ST188F-1040003 Valve, Intake 1
72
ST188F-1040011 Valve, Exhaust 1
73
ST188F-1040010-2 Push Rod 2
74
ST188F-1040006 Retainer, Valve Spring 2
75
ST188F-1040004 Valve Seal 2
76
ST188F-1040007 Valve Spring 2
77
ST168F-1040027 Stud, Bolt 2
78
ST188F-1040002 Retainer, Intake Valve 1
79
ST188F-1040008 Retainer, Exhaust Valve 1
80
ST188F-1040009 Rotator, Exhaust Valve 1
81
ST188F-1040028 Guide Plate, Push Rod 1
82
ST188F-1040021 Shaft, Rocker Arm 1
# Part Number Description Qty
83
ST188F-1040026 Retainer, Rocker Arm 1
84
ST188F-1040022 Rocker Arm, Intake Valve 1
85
ST188F-1040023 Rocker Arm, Exhaust Valve 1
86
GB90-W-6 Washer －6 2
87
ST160F-1040024 Screw, Valve Adjustment 2
88
GB41-N-6 Nut M6 5
89
ST160F-1040025 Adjusting Nut M6 2
90
ST188F-1010002 Stud Bolt 2
91
ST188FD-1130003 Gasket, Insulator 1
92
ST182F-1134000 Insulator, Carburetor 1
93
ST182F-1130002 Gasket, Carburetor 1
94
ST182F-1133000-G Carburetor Assembly 1
95
ST188F-1130100 Gasket, Base 1
96
ST188FD-1070006-A Clip(－8) 3
97
188.091100.32 Base, Air Cleaner 1
98
GB5789-FB6-33 Flange Bolt M6x33 1
99
188.091003.35 Element, Air Cleaner 1
100
188.091102.35 Supporter, Air Cleaner 2
101
188.091200.36 Cover, Air Cleaner 1
102
ST188F-1090100-C Nut, Air Cleaner Cover 2
103
188.070013.04 Pipe , Air Cleaner 1
104
188.070014.04 Pipe 1
105
ST160F-1070007 clip(－7) 3
106
ST188F-1071400-GC Carbon Canister 1
107
168.070100.05 Fuel Tank Cap Assembly 1
108
188.070302.04 Warning Line 1
109
0902.070301.00 Fuel Filter 1
110
GB41-N-8 Nut M8 5
111
ST152FD-1070200 Inline Fuel Filter 1
112
ST1P68F-1070006-F Clip 1
113
188.071000.04 Fuel Tank 1
114
GB5789-FB8-32 Flange Bolt 8x32 2
115
ST188F-1070003-G Fuel Line 2 1
116
ST168F-1070200-G Fuel Cock 1
117
GB1667-S5-12 Bolt M5x12 1
118
ST188F-1070001-G Fuel Line 1 1
119
188.070010.31 Veil, Fuel Tank 1
120
21.001000.00 Switch 1
121
ST168F-1070003-G Knob, Fuel Cock 1
122
GB5781-B4-12 Bolt M4x12 1
123
ST188F-1110003 Shaft, Governor Arm 1
124
ST188F-1110005 Washer 8.2x17×0.8 1
125
ST188F-1030100 Oil Seal 1
126
ST188F-1110007 Pin Shaft 1
127
ST188F-1110006 Governor Arm 1
128
ST160F-1110004 Bolt, Governor Arm 1
129
ST188F-1110004 Spring, Governor 1
130
ST188F-1110001 Spring, Throttle Return 1
131
ST188F-1110002 Rod, Governor 1
132
188.080300.06 Control Assembly 1
133
168.111008.01 Sheath, Control Handle 1
134
ST188F-1010001 Bolt 2
135
ST188F-1100100-G Gasket, Exhaust Pipe 1
136
188.101001.11 Exhaust Pipe 1
137
GB96-FW-8 Flat Washer －8 7
138
GB90-W-8 Washer －8 5
139
GB93-LW-8 Lock Washer －8 2
140
GB41-N-8 Nut M8 2
141
ST168FD-1100003-CARB Gasket, SAI Valve 2
142
188.100500.00 Pipe, Connecter 1
143
GB93-LW-6 Lock Washer －6 2
144
ST168FD-1100300-CARB SAI Valve 1
145
GB5781-B6-16 Bolt M6×16 2
146
GB5781-B6-12 Bolt M6×12 3
147
GB93-LW-6 Lock Washer －6 3
148
188.101200.34 Muffler Protector 1
149
188.101300.34 Spark Arrester 1
150
GB1667-S4-6 Screw M4×6 4
151
GB90-W-5 Washer －5 5
152
GB93-LW-5 Lock Washer －5 5
153
GB5789-FB5-10 Flange Bolt M5×10 5
154
188.100001.34 Gasket, Muffler 1
155
188.101100.11 Muffler 1
156
GB41-N-6 Nut M6 3
157
182.131017.02 Standard Main Jet 1
182.131017.03 Altitude Main Jet –
