Oil
Use 4-Cycle automotive oil.
Oil capacity is 1.16 qt. (1.1 L).
Please reference the following chart for recommended
oil types for use in the log splitter.
Fuel
Fuel capacity is 1.64 gal. (6.2 L). Use regular unleaded
gasoline with a minimum octane rating of 85 and an
ethanol content of less than 10% by volume.
Hydraulic Oil System
Oil capacity is 9 gallons (34 L).
Use types 10W AW32, ASLE H-150, ISO32 or universal
hydraulic fluid.
Spin-On Filter – 15GPM, 10 Micron, ¾-16 Thread.
Engine Specifications
– Model ............................ 61121
– Displacement ...................... 338 cc
– Type ........................ 4-Stroke OHV
– Start Type ......................... Recoil
SPECIFICATIONS
When temperature is below 32º F (0ºC) use
universal tractor/transmission fluid.
NOTE
Maintenance Valve Clearance
– Intake: 0.13 – 0.17 mm (0.005 – 0.007 in.)
– Exhaust: 0.18 – 0.22 mm (0.007 – 0.009 in.)
Note: Tech bulletin regarding the valve adjustment
procedure is on www.championpowerequipment.com.
Spark Plugs
OEM spark plug: NHSP F6RTC
Replacement spark plug: NGK BPR6ES or equivalent
Make certain the spark plug gap is 0.7 - 0.8 mm or
(0.028 - 0.031 in.).
Log Splitter Specifications
– Ram Force ........................ 30 Ton
– Cycle Time ..................... 15 seconds
– Hydraulic Tank Capacity .......... 7 gal. (26.5 L)
– Max Log Length ............... 24-in. (61 cm)
– Max Log Weight .............. 100 lb. (45 kg)
– Coupler Ball Size ................. 2-in. (5 cm)
– Tire Size .................. 16-in. (40.6 cm)
– Max towing speed ........... 45 MPH (72 KPH)
– Engine ................. 338 cc, OHV, 4 stroke
– Cylinder size ... 4.72 in. x 23 in. (12 cm x 58.4 cm)
– Cylinder rod size ............. 1.84 in. (4.5 cm)
– Gear Pump ........................ 2-stage
– Max pressure ..................... 3500 psi
– Max flow capacity .................. 13 GPM
– Control Valve ............. Detent (auto-return)
Overall Dimensions
– Gross Weight .............. 573.2 lb. (260 kg)
– Net Weight .................. 518 lb. (235 kg)
– Height ................. 45.87 in. (116.5 cm)
– Width ................. 40.98 in. (104.1 cm)
– Length. . . . . . . . . . . . . . . . . . . 86.22 in. (219 cm)
