REV 93020-20120419 22
93020 ENGLISH
Parts List
# Part Number Description Qty
1
PMJ30-02 Beam 1
2
GB/T 889.1-2000 Lock Nut M12 8
3
GB/T 95-2000 Washer 12 7
4
PMJ22J-04-00 Wedge Slide 1
5
PMJ22J-20 Bolt 1
6
PMJ22J-12 Control Valve 1
7
GB/T 818-2000 Bolt M8×12 2
8
GB/ T 859-1987 Washer 8 2
9
PMJ22J-19 Plate 1
10
PMJ22G-51 Filter Housing "IN" Connection 1
11
PMJ22G-49
Filter Housing "OUT"
Connection
2
12
JB/T 8870－1999 Clamp d25 2
13
PMJ22G-25 Valve Joiner 1
14
GB3452.1-92 "O" Ring 14×2.65 1
15
PMJ22G-22 Front Cover Connection 1
16
PMJ22G-24 Valve Joiner 1
17
GB 982-1977 Combination Washer 14 4
18
PMJ22G-23 Bolt Connection 2
19
PMJ22J-13 Hydraulic Hose(Valve-Cylinder) 1
20
PMJ30-08-00 Cylinder 1
21
PMJ30-03 Cylinder Fixing Plate 2
22
GB/T 95-2000 Washer 8 12
23
GB/T 93-1987 Lock Washer 8 12
24
GB/T 5783-2000 Bolt M8x20 12
25
PMJ22J-18 Hydraulic Hose(Valve-Pump) 1
26
GB/T 5781-2000 Bolt M10x15 8
27
GB/T 93-1987 Lock Washer 10 16
28
GB/T 95-2000 Washer 10 16
29
PMJ30F-01 Log Catcher 2
30
PMJ22J-15 Pin 1
31
PMJ22G-30 R Pin 2
32
PMJ22G-15 Hydraulic Hose(Valve-Oil Tank) 1
33
GB/T 3452.1-92 "O" Ring 10×2.65 1
34
PMJ22G-21 Outlet Connector Of Pump 1
35
GB/ T 1096-1979 Flat Key 1
36
PMJ22G-26 Gear Pump Connector 1
37
PMJ30-23 Gear Pump Stand 1
38
PMJ30-28 Engine Connector 1
39
PMJ30-29 Engine Bushing 1
40
PMJ30-32 Key 1
41
GB/T 5782-2000 Bolt M12x70 1
42
JB/T 8870－1999 Clamp d40 2
43
PMJ30-10 Gear Pump 1
# Part Number Description Qty
44
GB/T 77-2000 Screw M6×10 1
45
ASME B18.2.1 1996 Bolt 5/16"-24×1" 4
46
PMJ35-338CC-GC10 Engine 1
47
GB/T 5780-2000 Bolt M10x45 4
48
GB/T 41-2000 Nut M10 8
49
PMJ30-06 Base Tube 1
50
GB/T 5782-2000 Bolt M12×65 2
51
PMJ22J-01-00 Base Connector 1
52
PMJ22J-10 Pin 1
53
GB /T 97.2-1985 Washer 12 4
54
GB/T 5782-2000 Bolt M12×90 1
55
GB/T 5782-2000 Bolt M12×80 2
56
PMJ22G-40 2" Coupler 1
57
PMJ22G-41 Safety Chain With Hook 2
58
PMJ22J-07-00 Front Support Leg 1
59
PMJ30-17 Oil Pipe 1
60
GB/T 70.1-2000 Screw M5×20 6
61
GB/T 93-1987 Lock Washer 5 6
62
GB/ T 95-1985 Washer 5 6
63
PMJ22G-07-00 Filter Fix Plate 1
64
PMJ22G-44 Filter 1
65
GB/T 3452.1-92 "O" Ring 80×3.55 1
66
PMJ22G-52 Auto Filter 1
67
PMJ22G-50 Auto Filter Base 1
68
PMJ22G-19 Oil Plug 1
69
PMJ30-01 Oil Tank 1
70
PMJ22G-35-00 Right Fender 1
71
GB/T 5782-2000 Bolt M12×85 2
72
PMJ22G-12 Hinge Pin 1
73
PMJ22G-18 Screw NPT1" 1
74
GJY12-3 R Pin 1
75
GB/T 5781-2000 Bolt M10x30 4
76
PMJ22G-34-00 Left Fender 1
77
GB/T 91-2000 Cotter Pin 4×32 2
78
PMJ22J-05-01 Cased Seal 2
79
L44634 LYC DS Tapered Bearing 4
80
PMJ22J-05-03 Wheel 2
81
GB/T 9459-1988 Slotted Nut M20x1.5 2
82
PMJ22J-05-02 Axle Cap 2
83
PMJ22G-38 Big Tension Spring 1
84
GB/T 798-1988 Swing Bolt M8x28 1
85
GB/T 6170-2000 Nut M8 1
86
GB 1160.2-89 Oil Scale 1
