17
Stiletto Boombox System
Optional Accessories
The following optional accessories are available for purchase from your SIRIUS retailer to maximize your SIRIUS experi-
ence:
Directed 14130, 20 foot SIRIUS antenna extension
Directed 14230, 50 foot SIRIUS antenna extension
Directed 14220, DBS combiner/splitter system
Directed 14240, SIRIUS Outdoor Antenna
Directed 14250, SIRIUS CATV Signal/Distribution System
Nominal Output Power per Channel......5 Watts RMS x 2, 10 Watts x 1 (woofer)
(30W total peak music power, 1% THD+N)
Total Harmonic Distortion (THD).......................................................0.1% at 1 Watt
Speaker Frequency Response.........................................................70Hz to 20KHz
Signal-to-Noise ratio (S/N).........................................................>75dB Minimum
Headphone Output Impedance..............................................................32 Ohms
Headphone Output Level (Variable).......................................500mV (Minimum)
Headphone Connector Type........................................3.5mm Stereo Jack (1/8")
Auxiliary Input Impedance...................................................3K Ohms (Nominal)
Auxiliary Input Level...........................................................2.0 Volts (Maximum)
Auxiliary Input Connector ..........................................3.5mm Stereo Jack (1/8")
Battery type/Quantity..................................................................."D" Cell/8 Total
AC Adapter ................................................................12 Volt, 3A, Center Positive
Overall Dimensions (W x H x D).......................................................19.2"x8.8"x8"
(487mm x 223mm x 205mm)
Weight (Without Batteries)..........................................................................3.3Kg
Specifications
