12
Antenna Aiming
Adjust your antenna
position to maximize signal
strenght
SATELLITE
TERRESTRIAL
Press SELECT when done
For example, suppose you live in AREA 2. You determined that your antenna will need to have a clear view of the sky facing
NORTH or NORTHEAST. The exact direction is determined by your specific location in Area 2 relative to the X on the map:
If you live in Texas, you will need a more NORTH facing clear view of the skp whereas if you live in southern California, you
will need a more NORTHWEST facing clear view of the sky.
Once you have found a suitable location for the antenna, route the antenna cable to the Boombox. Be sure you avoid any
obstructions that could crimp, kink, or twist the cable. Use protective grommets wherever rough openings are encoun-
tered. If the antenna is installed outdoors, route the cable from the antenna locations to the interior of the home, working
the cable trhough the basement, under a window sill, etc., and make adjustments to take up cable slack as necessary.
Connect the antenna extension cable to the ANT connection on the rear of the Boombox. Optional antenna extension
cables are available if needed. Refer to the Optional Accessories section for more details.
Testing and Optimizing the Antenna Signal Strength
The stronger the SIRIUS signal strength, the less likely it is that you will
experience an interruption of the audio when listening to a broadcast. To
assist you in adjusting the antenna aiming for optimal reception, your
SIRIUS radio can display a screen similar to showing the strength of the
SIRIUS signal being received.
To access the antenna aiming or signal indicator screen, consult the man-
ual which accompanied your SIRIUS radio. The SATELLITE portion of the
display screen shows the strength of the signal being received from the
satellite, while the TERRESTRIAL portion of the display screen shows the
strength of the signal being received from terrestrial based transmitters,
if available. Make small adjustments to the aiming of the antenna until
you achieve the strongest possible signal.
