Starmate Replay STB2 Boombox User Guide
5
Installation
AC Power Connection: If you are using the AC
power adapter, connect the AC power cord to the AC
power adapter first. Then plug the AC power cord
into an outlet.
Antenna Connection: Plug the windowsill antenna
connector into the ANT connector on the rear of the
Boombox, pushing firmly until the connector is fully
seated.
Battery Installation: The Boombox can operate on
eight “D” size batteries when AC power is not
available. Install the batteries as follows:
1. At the rear of the Boombox, press the battery
cover latches down toward the bottom of the
Boombox and pull the battery compartment
cover to open.
2. Insert eight “D” size batteries into the battery
compartment, being careful to observe the
battery polarity as shown in the battery
compartment.
3. When the batteries are correctly installed, close
the battery compartment cover.
Installing/Removing the Starmate Replay
Receiver:
Insert the connector from the Boombox
into the connectors on the left side of the receiver.
Then place the bottom of the receiver into the
Boombox and tilt the top of the receiver into the
Boombox until it snaps into place.
To remove the receiver from the Boombox, pull the
top of the receiver out enough so that the receiver
can be lifted out. Disconnect the connector on the
left side of the receiver.
Antenna Placement: Proper installation of the
windowsill antenna is important for consistent
satellite signal reception.
For correct operation and best reception of the
SIRIUS signal, it is important that the antenna is
located in a place where it will have a clear view of
the SIRIUS satellites in the sky. Obstructions such
as bushes, trees, other homes or buildings,
overhangs, soffits, chimneys, gables, dormers, etc.,
will impair or prevent the antenna from receiving a
signal.
The best reception is obtained if the antenna is
located outside, and the pod portion of the antenna
