Sirius Satellite Radio SP-B1 Portable Stereo System User Manual



Sportster SP-B1 User Guide
8
SP-B1 Specifications
Nominal Output Power per Channel ......................................................................................... 5 Watts RMS
Total Harmonic Distortion (THD) ............................................................................................ 0.3% at 1 Watt
Frequency Response ............................................................................................................. 30Hz to 20kHz
Signal-to-Noise Ratio (S/N) ................................................................................................. >65dB Maximum
Headphone Output Impedance ......................................................................................................... 32ohms
Headphone Output Level (Variable) ................................................................................ 500mV (Maximum)
Headphone Connector Type ................................................................................. 3.5mm Stereo Jack (1/8”)
Auxiliary Input Impedance ............................................................................................... 6K ohms (Nominal)
Auxiliary Input Level ...................................................................................................... 2.0 Volts (Maximum)
Auxiliary Connector Type ...................................................................................... 3.5mm Stereo Jack (1/8”)
Battery Type/Qty .................................................................................................................. “D” Cell / 8 Total
Overall Dimensions ........................................................................................... 17.5”(W) x 6-7/8”(D) x 8”(H)
........................................................................................................... 445mm(W) x 176mm(D) x 198mm (H)
Weight (Without Batteries) ...................................................................................................5.88lbs. (2670g)
