Sportster SP-B1 User Guide
5
Battery Installation
Your Boombox can operate independently of AC
power by installing 8 “D” batteries. The batteries
are bypassed automatically whenever the
supplied AC Adapter is plugged into the DC 12V
jack on the rear panel.
1. Turn the Boombox upside down to access the
battery compartment.
2. Push the battery cover latches forward and flip
up the battery compartment cover to the open
position
3. Insert eight 8 “D” batteries observing battery
polarity as shown, then close the cover.
Installing the SP-R1 Receiver in the SP-B1
Boombox
Place the SP-R1 Receiver in the SP-B1 Boombox
so that the guides are lined up with the ribs in the
Boombox cradle. Push the Receiver down to engage
the connectors. Push the top of the Receiver back
until it is flush with the front of the Boombox. It will
lock into place. Apply power to the Boombox by
pressing the Power button; the LED indicator lights
green. If the Receiver does not turn on at the same
time, press the RED Power ON/OFF button in the
upper left corner of the it’s front panel.
Removing the SP-R1 Receiver From the SP-B1
Boombox
Press the EJECT button on top of the Boombox; the
Receiver will partially eject forward. Using your
thumb and forefinger, grasp the Receiver on the
sides and pull up to disengage.
