Sportster SP-B1 User Guide
4
Boombox Controls
The SIRIUS Sportster SP-B1 Boombox provides four
control buttons, a Power On/Off, Volume Up, Volume
Down, and a push-button to toggle between Satellite
Radio or an auxiliary audio input signal. A power-on
LED is also located on the front panel.
3. AUX Jack: Accepts an audio input signal from an
external audio device. When using the AUX audio
input, turn the SIRIUS Sportster receiver Off to
preserve battery power. Adjust the volume level of
the external audio device to obtain an audio
output from the Boombox. The volume control on
the external audio device should be set to a mid-
range level for optimal fidelity.
4. Power On/Low Battery LED: The LED lights
green when the Power On/Off button is pressed.
The LED will light red to alert the user that the
batteries are nearly discharged. This condition
may cause degraded performance of the SP-B1.
5. Power ON/OFF Button: Applies power to the
Boombox when pressed.
6. Volume Control: Press the left (-) button to
decrease audio level. Press the right (+) button to
increase the audio level.
7. Release Button: Press this button to release the
Sportster Receiver from the Boombox cradle.
4
3
2
165
1. PHONES: Accepts a stereo headphone jack to
provide private listening capability for the Boombox.
2. SOURCE Selector Button: Push button toggles
between Satellite Radio and an external audio input
signal (MP3, CD, etc.) present at the AUX input
jack.
7
