Specifications
Specifications
Specifications
•
General
Frequency Range 28.0 to 29.7 MHz
Frequency Control Phase Lock Loop (PLL) synthesizer
Frequency Stability 0.005%
Operating
Temperature Range
-22°F to 122°F (-6°C to + 50°C)
Antenna Impedance 50 ohms
Antenna Connector Standard SO 239 type
Microphone Plug-in dynamic with Press-To-Talk switch and coiled cord
Input Voltage 13.8 V DC nominal, 15.9 V max., 10.0 V min.
(positive or negative ground)
Current Drain Transmit: 8.0 A AM/FM 15A SSB@100W PEP
Receive (squelched): 0.5 A
Receive (maximum audio output): 1.2 A
Size 2
3
⁄8"(H) x 7
7
⁄8"(W) x 10
3
⁄4"(D)
[6cm (H) x 20cm (W) x 27.3cm (D)]
Weight 6.5 lbs.
Meter (3-in-1) Illuminated – indicates relative output power,
received signal strength, and SWR.
Built-in Speaker 4 watts
Transmitter
Power Output Low – 4 watts AM/FM 12 watts SSB
High – 30 watts AM/FM 100 watts PEP SSB
Frequency Response 300 to 3,000 Hz
Frequency Tolerance 500 Hz
Transmit Distortion 2%
Spurious Harmonic
Emission
-65 dB
Output Indicators Meter shows relative RF output power and SWR.
Transmit LED glows red when transmitter is in operation.
Antenna Warning LED Glows red when SWR is greater than 3.0.
Specifications
•
Receiver
Sensitivity AM: 0.5 µV for 10 dB S/N
FM/SSB/CW: 0.25 µV for 12 dB S/N
Audio Frequency
Response
300 to 3,000 Hz
Maximum Signal
to Noise Ratio
45 dB
Image Rejection 65 dB
Adjacent AM/FM: 60 dB
Channel Rejection SSB/CW: 70 dB
RF Gain Control (AGC) 40 dB – adjustable for optimum signal reception
Squelch Adjustable – threshold less than 0.5 µV
Automatic Noise
Limiter (ANL)
Switchable
Noise Blanker (NB) Switchable
Receive Indicators Meter shows relative signal strength.
Receive LED glows green when receiving a signal.
External Speaker
Power Output 4 watts into external speaker
External Speaker
(Not Supplied)
8 ohms
(Specifications subject to change without notice)
