English
Display Adjust Mode
Turning the screen saver
function on or off
This unit features various screen saver patterns
that are exhibited across the display. If the
screen savers are not desired, they can be
turned off.
If the button operation is performed with the
screen saver function on, the operation display
corresponding to the button operation is shown
for about 30 seconds and the display returns to
the screen saver display.
∗ The factory default setting is “ON”.
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Press the [a]/[d] button to select
“SCREEN SVR”.
3. Turn the [ROTARY] knob to select the setting.
Each time you turn the [ROTARY] knob, the
setting changes in the following order:
OFF ➜ ON ➜ MESSAGE
4. Press the [DISP] button to return to the previ-
ous mode.
Entering MESSAGE
INFORMATION
When “MESSAGE” is selected for the screen
saver setting, you can change the contents of the
message.
∗ Up to 30 characters can be entered.
∗ The factory default setting is “Welcome to Clarion”.
1. Press and hold the [DISP] button for 1 second
or longer to switch to the display adjust mode.
2. Press the [a]/[d] button to select
“MSG INPUT
EE
EE
E”.
3. Press the [ ] button.
4. Press the [a]/[d] button to move the cursor.
5. Press the [BND] button to select a character.
Each time you press the [BND] button, the
character changes in the following orders:
Capital letters ➜ Small letters ➜ Numbers
and Symbols ➜ Umlaut ➜ Capital letters…
6. Turn the [ROTARY] knob to select the desired
character.
7. Repeat steps 4 to 6 to enter up to 30 charac-
ters for message.
Common Operations
Setting the down mix
This function allows you to select the method of
down-mixing when the channel format and the
output channel configuration are not in
agreement.
∗ This function can be operated only when the
speakers other than FRONT-SP are set to
“OFF” in “SP-SEL”.
∗ The factory default setting is “Lo/Ro”.
1. Following the steps 1 to 3 in “Selecting the
monitor menu”, select “DOWN MIX” from
“AUDIO SETUP”.
2. Press “ ” button to go to the right pane.
3. Press “ ” or “ ” buttons to select “Lo/Ro” or
“Lt/Rt”.
“Lo/Ro”: Down-mixing the discrete 5-channel
master etc. to 2-channel stereo track
“Lt/Rt”: Writing down matrix-encoded sounds
to 2-channel stereo track
4. Press the [ENT] button.
Changing Initial Settings such as
Menu Language, etc.
+VXZ758R_01-09-Eng.p65 05.3.2, 3:32 PM44
