Setting the speaker gain
∗ If you select “OFF” for this function, you cannot
adjust the speaker gain.
∗ This function appears only when there is no
disc loaded or playback stops.
∗ The factory default setting is “OFF”.
1. Following the steps 1 to 3 in “Selecting the
monitor menu”, select “SP-GAIN SET” from
“AUDIO SETUP”, and press the “ ” button
to go to the option list.
2. Press “ ” or “ ” buttons to select “ON” or
“OFF”.
3. Press the [ENT] button.
Adjusting the speaker gain
∗
This function cannot be operated when the disc is
loaded or when “SP-GAIN SET” is set to “OFF”.
∗
You cannot adjust the speaker gain for speakers
set to “OFF” in “SP-SEL”.
∗ The factory default setting is “0 dB”.
1. Following the steps 1 to 3 in “Selecting the
monitor menu”, select “SP-GAIN” from
“AUDIO SETUP”.
2. Press the [ENT] button to display the SP-
GAIN screen.
Changing Initial Settings such as Menu Language, etc.
3. Press “ ” or “ ” buttons to select the
speaker.
Each time you press the buttons, you can switch
among speakers.
FRONT L
CENTER
FRONT R
SRD L
SRD R
SUB-WOOFER
The test tone is output from the speaker you
select.
4. Press “ ” button to go to the right pane.
5. Press “ ” or “ ” buttons to adjust the
speaker gain. The gain level ranges from “-
6dB” to “+6dB”.
6. Press the “ ” button to go back to the left
pane.
7. Repeat steps 3 to 5 to adjust the each
speaker gain.
Note:
• The test tone will not be output when DVD or CD
is being played with mute ON.
In that case, press the [MUTE] button on the
remote control unit to cancel the mute, or adjust
the volume.
Adjusting the speaker delay
time
The time necessary for sound to travel from
speakers to a listener differs depending on the
speaker location or the car size. By adjusting the
delay time of each speaker, you can hear the
sound from the front speakers and the other
speakers simultaneously.
