English
M275
Basic Operations
3. Turning the
[
ROTARY
]
knob to adjust the
selected Sound mode.
Z-EHCR :
Selection type : OFF B-BOOST
IMPACT EXCITE OFF...
BASS :
Adjustment range : -7 to
+
7
TREBLE :
Adjustment range : -7 to +7
BALANCE :
Adjustment range : LEFT 12 to RIGHT 12
FADER :
Adjustment range : FRONT 12 to REAR 12
Notes:
If no operation is performed for more than 10 sec
-
onds, the Audio mode is cancelled and returns to
the previous mode.
Bass and Treble can only be adjusted when the
“Z-EHCR” is off.
Adjusting the bass
2-1. Press the
[
,
]
button and select
“BASS”.
3-1. Turning the
[
ROTARY
]
knob clockwise em
-
phasizes the bass; turning it counterclock-
wise attenuates the bass.
“BASS XX” will be displayed where “
XX” is
the value from -7 to
+
7.
Note:
The factory default setting is “BASS 0”.
Adjusting the treble
2-1. Press the
[
,
]
button and select
“TREBLE”.
3-1. Turning the
[
ROTARY
]
knob clockwise em
-
phasizes the bass; turning it counterclock-
wise attenuates the bass.
“TREB XX” will be displayed where “XX” is
the value from -7 to
+
7.
Note:
The factory default setting is “TREB 0”.
Adjusting the balance
2-1. Press the
[
,
]
button and select
“BALANCE”.
3-1. Turning the
[
ROTARY
]
knob clockwise em
-
phasizes the sound from the right speaker;
turning it counterclockwise emphasizes the
sound from the left speaker.
The display changes as follows:
“RIGHT XX” will be displayed where “
XX” is
the value from 1 to 12.
“LEFT XX” will be displayed where “
XX” is
the value from 1 to 12.
Notes:
When Balance is 0, “
CENTER” will be displayed
instead.
The factory default setting is “
CENTER”.
Setting the Z-Enhancer
This unit is provided with 3 types of sound tone
effects stored in memory. Select the one you pre-
fer.
2-1. Press the
[
,
]
button and select “Z-
EHCR”.
3-1. Turning the
[
ROTARY
]
knob to change to the
following sound tone effect.
“OFF”
“B-BOOST”
“IMPACT”
“EXCITE”
OFF : no sound effect
B-BOOST : bass emphasized
(
indicator lights in the display
)
IMPACT : bass and treble emphasized
(
indicator lights in the display
)
EXCITE : bass and treble emphasized mid
de-emphasized
(
indicator lights in the display
)
Note:
The factory default setting is “
OFF”.
