English
M275
Basic Operations
Adjusting MAGNA BASS EX
The MAGNA BASS EX does not adjust the low
sound area like the normal sound adjustment
function, but emphasizes the deep bass sound
area to provide you with a dynamic sound.
1. Press and hold the
[
]
button for 1 second
or longer to turn on the MAGNA BASS EX ef
-
fect.
indicator lights in the display.
2. Press and hold the
[
]
button for 1 second
or longer to turn off the MAGNA BASS EX ef
-
fect.
indicator goes off from the display.
Note:
The factory default setting is “OFF”.
AUX function
This system has an external jack input in the front
panel where you can listen to sounds and music
from external devices connected to this unit.
1. Connect the external music player to the
[
AUX
]
input.
2. Press the
[
SRC
]
button and select the AUX
mode to activate the AUX function.
Adjusting the fader
2-1. Press the
[
,
]
button and select
“FADER”.
3-1. Turning the
[
ROTARY
]
knob clockwise em
-
phasizes the sound from the front speakers;
turning it counterclockwise emphasizes the
sound from the rear speakers.
The display changes as follows:
“FRONT XX” will be displayed where “
XX” is
the value from 1 to 12.
“REAR XX” will be displayed where “
XX” is
the value from 1 to 12.
Notes:
When Fader is 0, “CENTER” will be displayed
instead.
The factory default setting is “
CENTER”.
Notes:
Use only the 3.5mm stereo jack for the AUX jack
input.
Volume can be adjusted through the unit. If you
face difficulties of hearing sound even after volume
has been adjusted, please refer section “Selecting
AUX IN sensitivity” on page 20 for details.
