Page 22 CCRadio-SWP
Specifications
1. Frequency Coverage:
FM 70.0 ~ 108.0MHz
AM (MW) 522 ~ 1628kHz (9k step)
520 ~ 1710kHz (10k step)
SW1 2300 ~ 7500kHz
SW2 9200 ~ 22000kHz
2. S/N (Signal to Noise) Sensitivity:
FM > 10uV
AM > 1mv/m (this is extraordinary)
SW > 30uV
3. AM Selectivity: > 25dB
4. Number of Memories: 200
5. Power Source:
2 (AA Size) or LR2
DC IN: 3V 150mA, Tip (-) 3.5mm x 1.3mm
6. Built-in Speaker: 25ohm 0.5W
7. Earphone Socket: 3.5mm 32ohm
8. Dimensions: 4.75" W x 3" H x 1.2" D
If you have purchased an optional AC-DC
adapter, be sure it is the correct voltage. It
should have an output of three Volts DC with
the center negative, and not less than 150
MAh. Use only the recommended adapter.
Otherwise it may damage the radio or cause a
fire or electric shock.
Power Adapter
