Command Line Interface (CLI) AP-700 User Guide
Configuring the AP using CLI commands
185
Set Ethernet Speed and Transmission Mode
[Device-Name]>set etherspeed <value> (see below)
[Device-Name]>reboot 0
Set Interface Management Services
Edit Management IP Access Table
[Device-Name]>set mgmtipaccesstbl <index> ipaddr <IP address> ipmask <subnet mask>
Configure Management Ports
[Device-Name]>set snmpifbitmask <(see below)>
[Device-Name]>set httpifbitmask <(see below)>
[Device-Name]>set telifbitmask <(see below)>
Choose from the following values:
Set Communication Ports
[Device-Name]>set httpport <HTTP port number (default is 80)>
[Device-Name]>set telport <Telnet port number (default is 23)>
Configure Secure Socket Layer (HTTPS)
Enabling SSL and configuring a passphrase allows encrypted Secure Socket Layer communications to the AP through
the HTTPS interface.
[Device-Name]>set sslstatus <enable/disable>
The user must change the SSL passphrase when uploading a new certificate/private key pair, which will have a
corresponding passphrase.
[Device-Name]>set sslpassphrase <SSL certificate passphrase>
[Device-Name]>show http (to view all HTTP configuration information including SSL.)
Ethernet Speed and
Transmission Mode
Value
10 Mbits/sec - half duplex 10halfduplex
10 Mbits/sec - full duplex 10fullduplex
10 Mbits/sec - auto duplex 10autoduplex
100 Mbits/sec - half duplex 100halfduplex
100 Mbits/sec - full duplex 100fullduplex
Auto Speed - half duplex autohalfduplex
Auto Speed - auto duplex autoautoduplex (default)
Interface Bitmask Description
0 or 2 = Disable (all interfaces) All management channels disabled
1 or 3 = Ethernet only Ethernet only enabled
4 or 6 = Wireless only Wireless A only enabled
5 or 7 = Enable all interfaces All management channels enabled
