HandyTone -286 User Manual Grandstream Networks, Inc.
33
Volume
Amplification
Handset volume adjustment. RX is for receiving volume, TX is for
transmission volume. Default values are 0dB for both parameters. +6dB
generates the highest volume and -6dB generates the lowest volume.
Call Progress Tones
Using these settings, users can configure various call progress tone frequencies
and cadences according to their country standard. By default they are set to
North American standard.
Frequencies should be configured with known values to avoid uncomfortable
high pitch sounds. ON is the period of ringing (“On time” in ‘ms’) while OFF
is the period of silence. In order to set a continuous ring, OFF should be zero.
Otherwise it will ring ON ms and a pause of OFF ms and then repeat the
pattern. Up to three cadences are supported.
6.2.4 Saving the Configuration Changes
Once a change is made, the user should press the “Update” button in the Configuration Menu. The IP
phone will then display the following screen to confirm that the changes have been saved.
Grandstream Device Configuration
STATUS BASIC SETTINGS ADVANCED SETTINGS
Your configuration changes have been saved.
They will take effect on next reboot.
All Rights Reserved Grandstream Networks, Inc. 2005
Users are recommended to power cycle the HandyTone-286 after seeing the above message.
6.2.5 Rebooting the HandyTone-286 from Remote
The administrator of the phone can remotely reboot the phone by pressing the “Reboot” button at the
bottom of the configuration menu. Once done, the following screen will be displayed to indicate that
rebooting is underway.
