HandyTone -286 User Manual Grandstream Networks, Inc.
22
6.2.3 Advanced User Configuration
To login to the Advanced User Configuration page, follow the instruction in section 6.2.1 to get to the
following login page. The password is case sensitive with a maximum length of 25 characters and the
factory default password for Advanced User is “admin”.
Grandstream Device Configuration
STATUS BASIC SETTINGS ADVANCED SETTINGS
Admin Password:
(purposely not displayed for security
protection)
SIP Server:
sip.mycompany.com
(e.g., sip.mycompany.com, or IP address)
Outbound Prox
:
(e.g., proxy.myprovider.com, or IP address, if
any)
SIP User ID:
123456789
(the user part of an SIP address)
Authenticate ID:
123456789
(can be identical to or different from SIP User
ID)
Authenticate Password:
(purposely not displayed for security
protection)
Name:
(optional, e.g., John Doe)
Advanced Options:
referred Vocoder:
(in listed order)
choice 1:
current setting is " PCMU"
choice 2:
current setting is " PCMA"
choice 3:
current setting is " G723"
choice 4:
current setting is " G729"
choice 5:
current setting is " G726-32"
choice 6:
current setting is " iLBC"
choice 7:
current setting is " PCMU"
G723 rate:
6.3kbps encoding rate 5.3kbps encoding rate
