REV 92207-20110916 16
92207 ENGLISH
Parts List
# Part number Description Qty
1
PMJ22J-02-00 Beam 1
2
GB/T 5782-2000 BOLT M12×75 (12.9) 1
3
PMJ22J-04-00 Wedge Slide 1
4
GB/T 95-2000 Washer 12 mm
7
5
GB/T 889.1-2000 Lock Nut M12
8
6
PMJ22G-51 Filter Housing “IN” Connection
1
7
PMJ22J-12 Control Valve
1
8
PMJ22G-24 Valve Joiner
1
9
JB 982-1977 Combination Washer 14 mm
4
10
PMJ22G-25 Valve Joiner
1
11
GB3452.1-92 “O” Ring 14×2.65
1
12
PMJ22G-22 Front Cover Connector
1
13
PMJ22G-23 Bolt Connector
2
14
PMJ22G-49 Filter Housing “OUT” Connection
2
15
JB/T 8870 1999 Clamp D25
2
16
PMJ22G-16 Hydraulic Hose (Valve-Cylinder)
1
17
PMJ22J-08-00 Cylinder
1
18
GB/T 5783-2000 Bolt M8×20
8
19
GB/T 93-1987 Lock Washer 8 mm
20
20
GB/T 95-2000 Washer 8 mm
20
21
PMJ22J-03 Cylinder Mounting Plate
2
22
PMJ22J-15 Pin
1
23
PMJ22G-30 R-Pin
2
24
PMJ22G-15 Hydraulic Hose (Valve-Oil Tank)
1
25
PMJ22J-09-00 Pin
2
26
PMJ22J-06 Base Tube
1
27
PMJ22J-01-00 Base Connector
1
28
PMJ22J-10 Pin
1
29
PMJ22G-40 2” Coupler
1
30
GB/T 5782-2000 Bolt M12×80
2
31
PMJ22J-07-00 Front Support Leg
1
32
PMJ22G-41 Safety Chain With Hook
2
33
GB/T 97.2-1985 Washer 12
4
34
GB/T 5782-2000 Bolt M12×90
1
35
GB/T 5782-2000 Bolt M12×65
2
36
PMJ22J-18 Hydraulic Hos e(Valve-Pump)
1
37
GB/T 3452.1-92 “O” Ring 10×2.65
1
38
PMJ22G-21 Outlet Connector Of Pump
1
39
PMJ22J-14 Gear Pump
1
40
JB/T 8870 1999 Clamp D40
2
41
PMJ22G-17 Oil Hose
1
42
GB/T 5783-2000 Bolt M8×30
4
# Part number Description Qty
43
GB/T 6170-2000 Nut M8
9
44
GB/T 77-2000 Screw M6×10
1
45
PMJ22G-26 Gear Pump Connector
1
46
ASME B18.2.1 1996 Bolt 5/16”-24×1”
4
47
PMJ22G-29 Engine Bushing
1
48
PMJ22G-48 Engine
1
49
GB/T 1096-1979 Flat Key
1
50
PMJ22G-28 Engine Connector
1
51
PMJ22G-27 Gear Pump Stand
1
52
PMJ22G-32 Connector Cover
1
53
GB/T 845C-1985 Tapping Screw
4
54
GB/T 848-1985 Lock Washer 4 mm
4
55
GB/T 859-1987 Washer 4 mm
4
56
GB/T 1096-1979 Flat Key
1
57
GB/T 70.1-2000 Screw M5×20
6
58
GB/T 93-1987 Lock Washer 5 mm
6
59
GB/T 95-1985 Washer 5 mm
6
60
PMJ22G-07-00 Filter Fix Plate
1
61
PMJ22G-44 Filter
1
62
PMJ22G-19 Oil Plug
1
63
GB/T 3452.1-92 “O” Ring 80×3.55
1
64
GB/T 5782-2000 Bolt M8×45
4
65
PMJ22G-52 Auto Filter
1
66
PMJ22G-50 Auto Filter Base
1
67
PMJ22G-18 Screw NPT 1”
1
68
GJY12-3 R-Pin
1
69
GB/T 5782-2000 Bolt M12×85
2
70
PMJ22G-12 Hinge Pin
1
71
PMJ22J-11-00 Oil Tank
1
72
GB/T 91-2000 Cotter Pin 4×32
2
73
PMJ22J-05-01 Cased Seal
2
74
L44634 LYC DS Tapered Bearing
4
75
PMJ22J-05-03 Wheel
2
76
GB/T 9459-1988 Slotted Nut M20x1.5
2
77
PMJ22J-05-02 Axle Cap
2
78
PMJ22J-19 Plate
1
79
GB/T 859-1987 Washer 8 mm
2
80
GB/T 70.2-2000 Bolt M8x12
2
81
PMJ22G-38 Big Tension Spring
1
82
GB/T 798-1988 Swing Bolt M8x28
1
83
GB 1160.2-89 Oil scale
1
