Oil
Use 4-Cycle automotive oil.
Oil capacity is 0.63 qt (0.6 L).
Please reference the following chart for recommended
oil types for use in the log splitter.
Fuel
Fuel capacity is 0.93 gallons (3.5 L). Use regular
unleaded gasoline with a minimum octane rating of 85
and an ethanol content of less than 10% by volume.
Hydraulic Oil
Oil capacity is 5 gallons (18.9 L).
Use types 10W AW32, ASLE H-150, ISO32 or universal
hydraulic fluid.
Spin-On Filter – 15GPM, 10 Micron, ¾-16 Thread.
Engine Specifications
– Engine .................... 196 cc OHV CPE
– PTO Rotation ............... Counterclockwise
– Ignition Mode .............. TCI (transistorized)
– Displacement ...................... 196 cc
– Torque (max) .......... 8.7 ft. lb. @ 2800 RPM
– Compression ....................... 8.5:1
– Horizontal Shaft ............... . ¾” x 2 7/16”
. . . . . . . . . . . . . . . . . . . . . . (1.91 cm x 6.17 cm)
– End Hole .............. .Tapped 5/16” 24 UNF
– Fuel Capacity ............. 0.93 gallons (3.5 L)
– Weight ..................... 37.5 lb. (17 kg)
– Height ............... 13.35 inches (33.9 cm)
– Width ............... .12.13 inches (30.8 cm)
– Length. . . . . . . . . . . . . . . 14.25 inches (36.2 cm)
Log Splitter Specifications
– Ram Force ........................ 22 Ton
– Cycle Time ..................... 14 seconds
– Hydraulic Tank Capacity .......... 5 gal (18.9 L)
– Max Log Length ........ 23.75 inches (60.3 cm)
– Max Log Weight .............. 100 lb. (45 kg)
– Coupler Ball Size .............. 2 inches (5 cm)
– Tire Size ................. 15 inches (38 cm)
– Max towing speed ........... 45 MPH (72 KPH)
– Engine ................ .196 cc, OHV, 4 stroke
– Cylinder size ...... 4” x 22.63” (10 cm x 57.5 cm)
– Cylinder rod size ........... . 1.57 inches (4 cm)
– Hydraulic Fluid Type ............. . 10W AW32,
. . . . . . . . . . . . . . . . . . . . . .ASLE H-150, ISO 32
– Gear Pump ....................... . 2-stage
– Max pressure .................... .3500 psi
– Max flow capacity .................. 11 GPM
– Control Valve ............. Detent (auto-return)
– Overall Dimensions
– Gross Weight .............. 482.8 lb. (219 kg)
– Net Weight ................. 441 lb. (200 kg)
– Height .............. . 45.87 inches (116.5 cm)
– Width .............. .40.75 inches (103.5 cm)
– Length. . . . . . . . . . . . . . . . 85.83 inches (218 cm)
Spark Plugs
Recommended replacement spark plug:
– NGK BR6ES or equivalent
Make certain the spark plug gap is 0.7 - 0.8 mm or
(0.028 - 0.031 in.).
Valve Clearance
– Intake: 0.13 – 0.15 mm (0.005 – 0.006 in.)
– Exhaust: 0.18 – 0.20 mm (0.007 – 0.008 in.)
