PDS • User’s Guide 101
6. Upgrading Firmware
Upgrading Firmware Using the Web Upgrade
4. A message informs you if a new firmware version is available.
Figure 6-5. Firmware Version-Upgrade Message
5. Press <SEL> to start the upgrade. A message will inform you to “Please wait...”.
Figure 6-6. Upgrade Wait Message
6. After the upgrade is finished, the PDS will automatically reboot.
Figure 6-7. Resetting Message
If you are not connected to the internet, a message prompts you to check the
connection.
réÖê~ÇáåÖ=cáêãï~êÉ=rëáåÖ=íÜÉ=tÉÄ=fåíÉêÑ~ÅÉ
Use the following steps to upgrade PDS software:
1. Ensure that your PC (or laptop) uses Windows® 7, Windows® 2000, or Windows
XP.
2. xConnect the PDS’s Ethernet port to a Switch.
3. Connect the Switch to your PC (or laptop).
4. Power-up the PDS.
5. Note the PDS’s current IP address:
a. From the Status Menu, press SEL to display the Setup Menu.
b. Select System to display the System Menu.
c. Select Ethernet to display the Ethernet Menu.
Rev #.#.#
available. Upgrade?
<SEL> = Yes.
<ESC> = No.
Please wait ....
Resetting ....
Please wait
