CN8600 User Manual
150
Specifications
Function Specification
Connectors Console
Ports
KB 1 x USB Type A Female (White)
Video 1 x DVI-D Female (White)
Mouse 1 x USB Type A Female (White)
Audio Speaker 1 x Mini Stereo Jack Female (Green)
Microphone 1 x Mini Stereo Jack Female (Pink)
KVM Ports KB/Mouse 1 x USB Type B Female (White)
Video 1 x DVI-D Female (White)
Audio Speaker 1 x Mini Stereo Jack Female (Green)
Microphone 1 x Mini Stereo Jack Female (Pink)
LAN 2 x RJ-45 Female (Black)
Virtual Media / Laptop USB console 1 x USB Mini-B Female (Black)
Power 2 x DC Jack (Black)
PON 1 x RJ-45 Female (Black)
Serial Port 1 x RJ-45 Female (Black)
Control Port 1 x PS2 port
Switches Reset 1 x Semi-recessed pushbutton (Black)
USB Function Selection 1 x Slide Switch (Black)
Console Lock 1 x Slide Switch (Black)
Power 1 (Green)
LEDs Console Status 1 (Green)
LAN 10/100/1000 Mbps Orange: 10 Mbps
Orange + Green: 100 Mbps
Green: 1000 Mbps
Remote Login 1 (Green)
Emulation Keyboard/Mouse USB
Video Local Console: 1920 x 1200 @ 60 Hz RB
Remote: 1920 x 1200 @ 60 Hz RB
Power Consumption DC5.3V, 6W
Environme
nt
Operating Temp.
0–50
o
C
Storage Temp.
-20–60
o
C
Humidity 0–80% RH Non-condensing
Physical
Properties
Housing Metal
Weight 0.88 kg
Dimensions (L x W x H) 26.00 x 7.64 x 4.20 cm
