West Marine VHF50 Radio Owner’s Manual 17
WX Frequency Chart
Channel No. (MHz) Name
WX01 162.5500 WEATHER1
WX02 162.4000 WEATHER2
WX03 162.4750 WEATHER3
WX04 162.4250 WEATHER4
WX05 162.4500 WEATHER5
WX06 162.5000 WEATHER6
WX07 162.5250 WEATHER7
WX08 161.6500 WEATHER8
WX09 161.7750 WEATHER9
WX10 163.2750 WEATHR10
Accessories
Model Description Order #
SWIV200 Swivel Belt Clip with Button and Mounting Screw 3895638
BC50 12 Hr. Std. Charger with Cradle and AC power supply 5471495
DC200 DC Cigarette Lighter power supply for Std. Charger 3895554
BP50 Lithium Ion Rechargeable Battery Pack 5531538
ANT50 Flexible Rubber Antenna 3895547
West Marine VHF50 Radio Specifications
Dimensions
Operating Voltage 7.2Vdc
Battery Capacity 1200mAH Li-Ion
Transmitter
Frequency Range 156.025-157.425
Output Power 5W /1W
Spurious Emission 65@5W/ 55@1W
AF Distortion < 5%
Max Deviation < 5KHz
Frequency Stability < 5ppm
FM Hum & Noise > 40dB
Microphone Type Condenser
Adjacent Channel Power > 70dBc
Current Drain 1.5A / 0.7A
Receiver
Frequency Range 156.050-163.275
Sensitivity 0.2uV
Adjacent Channel Selectivity > 70dBc
Intermodulation Distortion > 65dBc
Spurious Response > 70dBc
AF Output 0.5W
Speaker Impedance 8 Ohm
NOTE: Performance specifications are nominal value, unless otherwise indicated,
and are subject to change without notice.
