Table 7-4: Basic Menu Structure
Menu Name
Radio Displays
(top and bottom lines)
Usage Notes
To/From Dwell Display
registration, RF sync and
transceiver status codes
Engineering Display
(Menu may not be
available per
programming.)
bit-error rates
and RSSI data
Displays radio system connection data. For engineering use.
OFF/ON
Silent Emergency
“SilentEmerg”
Use
to toggle Silent Emergency OFF/ON.
available modes
Operating Mode
(e.g., OTP, EDACS, etc.)
“Mode Menu”
Use
to choose an available mode. Press MENU and
confirm (Y/N) with
and press MENU again.
current latitude and
longitude
GPS Fix
“GPS Fix”
Radio’s current GPS latitude and longitude position scrolls
across top line of the display. Applies to GPS-equipped radios
only.
User ID # of user
currently logged in
User ID
“User ID”
User’s identification/name scrolls across top line of the display
(if programmed).
Radio’s IP address
IP Address
“IP Address”
Radio’s Internet Protocol (IP) address scrolls across top line of
the display.
station’s call sign
Station Identification
“Station ID”
Station’s identification/name scrolls across top line of the display
(if programmed).
“OFF”
Stealth Mode
“StealthMenu”
Use
to enable. Press any button to disable.
“LOW”, “MEDIUM”,
“MEDHIGH”, “HIGH”
Treble Level
“Treble Menu”
Use
to choose speaker/headset treble level. Press
Select to return to dwell display.
“<< >>”
Display Brightness
“Bright Menu”
Use
to dim or brighten. Press MENU to return to dwell
display.
“OFF”, “LOW”, “MED”,
“HIGH”
Side Tone Level
“Side Menu”
Use
to choose side tone level. Press MENU to return to
dwell display.
“ON” or “OFF”
Intercom
“INTERCOM”
Use
to turn intercom on and off. Press MENU to return to
dwell display.
selected channel Selected Channel
(Menu may not be
available per radio
programming)
“ChannelMenu”
Displays the current channel. Press MENU to return to dwell
display.
See Next Page
