MM-014716-001
11
2.2 COMPLIANCE WITH RF EXPOSURE STANDARDS
Your MA/COM, Inc. M7300 mobile two-way radio is designed and tested to comply with a number of
national and international standards and guidelines (listed below) regarding human exposure to RF
electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for
occupational/controlled RF exposure environment at duty factors of up to 50% talk-50% listen and is
authorized by the FCC for occupational use. In terms of measuring RF energy for compliance with the
FCC exposure guidelines, your radio antenna radiates measurable RF energy only while it is transmitting
(talking), not when it is receiving (listening) or in standby mode.
Your M/A COM, Inc. M7300 mobile two-way radio complies with the following RF energy exposure
standards and guidelines:
• United States Federal Communications Commission (FCC), Code of Federal Regulations; 47 CFR §§
2 sub-part J.
• American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE)
C95.1-2005.
• Institute of Electrical and Electronic Engineers (IEEE) C95.1-2005.
• IC standard RSS-102, Issue 2, 2005: “Spectrum Management and Telecommunications Radio
Standards Specification. Radiofrequency Exposure Compliance of Radiocommunication Apparatus
(All Frequency Bands).
CAUTION
Table 2-1 lists the recommended minimum lateral distance for a controlled environment
and for unaware bystanders in an uncontrolled environment, from transmitting types of
antennas (i.e., monopoles over a ground plane, or dipoles) at rated radio power for
mobile radios installed in a vehicle. Transmit only when unaware bystanders are at least
the uncontrolled recommended minimum lateral distance away from the transmitting
antenna.
2.2.1 Mobile Antennas
Table 2-1: Rated Power and Recommended Minimum Safe Lateral Distance
MOBILE RADIO
FREQUENCY
SPLIT
ANTENNA PART
NUMBER
DESCRIPTION
R
SAFE
CONTROLLED
ENVIRONMENT
(CM)
R
SAFE
UNCONTROLLED
ENVIRONMENT
(CM)
700/800 MHz
AN-025167-002
Dual Band 700/800,
Elevated Feed, Roof Mount
28 69
700/800 MHz
AN-025167-005
Combined GPS/700/800,
Elevated Feed, Roof Mount
28 69
700/800 MHz
AN-025167-015
Combined GPS/764-870,
Roof Mount
39 87
700/800 MHz
AN-025167-010
Dual Band 700/800, Low
Profile, Roof Mount
28 69
700/800 MHz
AN-025167-006
Dual Band 700/800,
Magnetic Mount
29 72
700/800 MHz
AN-025167-011
Combined GPS/700/800,
Low Profile, Roof Mount
28 69
700/800 MHz
AN-025167-001
Dual Band 700/800, Roof
Mount
28 69
700/800 MHz
AN-025167-004
Combined GPS/764-870,
Roof Mount
28 69
