25
2. Max outdoor temperature with the date and time of recording
3. Min dew point temperature with the date and time of
recording
4. Max dew point temperature with the date and time of
recording
5. Min outdoor humidity with the date and time of recording
6. Max outdoor humidity with the date and time of recording
MIN icon
MIN icon
Time and date
of recording
MIN dew point
value
MAX icon
MAX outdoor
humidity value
Time and date
of recording
26
7. Min Wind chill temperature with the date and time of
recording
8. Max Wind chill temperature with the date and time of
recording
9. Min Relative pressure with the date and time of recording
10. Max Relative pressure with the date and time of recording
11. Maximum wind speed with the date and time of recording
MIN icon
MIN wind chill
value
Time and date
of recording
MAX icon
MAX relative
pressure value
Time and date
or recording
27
12. Maximum Gust with the date and time of recording
13. Max 24 hour rainfall with the date and time of recording
MAX icon
MAX wind
speed value
Time and date
of recording
MAX icon
MAX wind gust
value
Time and date
of recording
28
RESET THE MAXIMUM AND MINIMUM WEATHER DATA
To reset the aforementioned maximum or minimum weather data 1. to
13., you shall need to reset each of the data independently.
1. Press MIN/MAX key to show the desired weather data. For
instance, if you want to reset the minimum humidity, in the normal
display you shall press the MIN/MAX key three times to show the
min humidity value.
2. Press and hold the SET key for about 2 seconds, then the
"RESET" icon will appear at the bottom part of the LCD.
3. Press the + key once, then the stored value will be reset to the
current value and current time.
4. Press the ALARM key to return to normal display mode.
14. Total rainfall amount
The total rainfall measurement is displayed in the fourth section of the
LCD, in the unit of mm or inch. It shows the total rainfall accumulated
since last reset of the weather station.
In normal display mode, press the MIN/MAX key fourteen times to show
the total rainfall value. The "RESET" icon will also be shown at the
same time.
24h rainfall value
MAX icon
