Introduction 13
Figure 1-2. SAN-Attached Cluster
Other Documents You May Need
CAUTION: The safety information that is shipped with your system provides
important safety and regulatory information. Warranty information may be
included within this document or as a separate document.
NOTE: To configure Dell blade server modules in a Dell PowerEdge cluster, see the
Using Dell Blade Servers in a Dell PowerEdge High Availability Cluster document
located on the Dell Support website at support.dell.com/manuals.
• The
Rack Installation Guide
included with your rack solution describes
how to install your system into a rack.
• The
Getting Started Guide
provides an overview of initially setting up your
system.
• The
Dell Failover Clusters with Microsoft Windows Server 2003 Installation
and Troubleshooting Guide
provides more information on deploying your
cluster with the Windows Server 2003 operating system.
• The
Dell Failover Clusters with Microsoft Windows Server 2008 Installation
and Troubleshooting Guide
provides more information on deploying your
cluster with the Windows Server 2008 operating system.
cluster node
cluster node
private network
Fibre Channel
connections
storage system
Fibre Channel
switch
Fibre Channel
switch
public network
Fibre Channel
connections
