Connecting to a TV
FOR GOOD RESULTS
SETTING UP YOUR PLAYER
Step 1:connect the audio cables to AUDIO OUT of the
DVD player..
Step 2:connect the yellow cable to the VIDEO on the
side of your player.
(For TVs that support S-Video Output please follow the
diagram on page 15.)
Remote Control
PREPARING THE REMOTE CONTROL
1. Open the cassette cover.
.
Slide the cover in the direction of
the arrow 2 while pushing down
the plastic retaining clip next to
the cover as the arrow 1.
2. place the battery into the
guide.
3. Insert the tray into the
remote control.
• When you place the battery into
the guide, make sure the polarity +
is faced up.
2
1
OPERATING WITH THE REMOTE CONTROL
Operating DVD video player with the
remote control.
The remote control must point at the
remote sensor on the front of the
player, in order for the DVD player to
function correctly.
!
1413
TV Audio Input
Red
White
TV Video Input
Yellow
REMOTE SENSOR
