Cowon Systems A2 Portable Multimedia Player User Manual



31
COWON A2
Higher the bps is better the quality of recordings, but the size of the fi le becomes larger and more bat-
Higher the bps is better the quality of recordings, but the size of the fi le becomes larger and more bat-
Product Details
General features
Size
133.4(W) x 78.5(H) x 22(T) mm
Weight
298g (common for 20 G/30 G)
Operation temperature range
0
~ 40
Video
Display
4 in., 480x272 resolution, 0.183 mm pixel pitch, 16 mega color Digital TFT LCD
Video format
NTSC / PAL
Audio
Channel
Stereo
Frequency range
20Hz ~ 20KHz
Headphone output
Stereo, left 32mW + right 32mW (16W earphones)
Signal to noise ratio
95dB
Built-in speaker
Stereo
Built-in microphone
Mono
FM radio
Frequency range
76~108 MHz (Country-specifi c frequency settings, 25 preset stations supported)
Antenna
Earphone cord antenna
Power supply
Built-in battery
Lithium polymer 4300mAh
Battery charge time
About 5 hours after AC adapter connection
AC adapter
DC 5.0V, 2A
Storage device
Hard disk
1.8 in. 20G / 30G, FAT32 File System
USB Interface
USB Device
USB 2.0 High Speed (max. 480Mbps)
USB Host
USB 2.0 Full Speed (max. 12Mbps)
PC environment
CPU : Pentium III 200Mhz or higher
OS : Windows XP / 2000 / ME / 98SE
RAM : 128MB or more
CD-ROM Drive
USB Port
DirectX 9 or higher
Windows Media Player 9 or higher
QuickTime 6 or higher
Hardware
