COWON A2
Advanced Features
AV OUT Usage
Connect external AV devices (TV, VTR, etc.) using the AV cable.
■
Connecting a Cable
Connect the AV cable to the “AV IN” of your A2 and the “AV IN (Video IN, Audio IN)” of the external AV device.
Change the AV device mode to an external input channel. For more information see the AV device manual.
Move the switch at the bottom of A2 to “AV OUT” and the screen from A2 will be displayed on the external AV device.
-
If the screen does not display properly check the following.
-
Check to see of the switch on the bottom of A2 is set to “AV OUT”.
-
Settings in Setup – Display – TV Standard are valid. (Select either NTSC or PAL)
-
Make sure the connection cable is connected properly.
-
Ensure the input jack and input channel are the same. (If connected to external input 1, must be set to external channel 1 for properly operation.)
