Features and Operation Explained — Back of Radio
ple antenna. A small diameter insulated stranded wire, about 60 feet in length is a good place
to start. Antenna wire can be attached by pressing the spring loaded lever and inserting the
wire. See “GROUND” jack
s to complete the antenna. If you are not familiar with external
wires we recommend hiring a qualified installer. See
Safety Instructions on page 25.
NOTE:
AM as we commonly call it in the United States is MW or Medium Wave in the rest of
the world.
The “GROUND” jack is used with the “MW (AM) EXTERNAL ANTENNA” jack a. Attach one
end of a length of wire to the “GROUND” jack and the other end to a good earth ground. See
“MW (
AM) EXTERNAL ANTENNA” jack a above for more information.
GROUND JACK
s
FM/SW EXTERNAL JACK
d
See “FM/SW ANTENNA” switch J on page 20 for more information. To connect to this jack, a
PAL type connector is needed.
Specifications
DIMENSIONS
11.4" W x 7.3" H x 2.75" D
(290mm x 185mm x 70mm)
WEIGHT
4.5 pounds without batteries
INPUT POWER
4 “AA” or 4 “D” size batteries
9V DC 500mA tip negative
AUDIO OUTPUT
2.5 Watt
SPEAKER
5 Watt 8 ohm
HEADPHONE JACK
3.5mm 32 ohm
AM DUAL CONVERSION
55.845 MHz 1st IF
455 kHz 2nd IF
AM IF OUTPUT
For expansion of
CW, SSB, DRM, SSTV, etc.
FREQUENCY COVERAGE
FM Band: 87.00 - 108 MHz Stereo
AM (MW) Band: 522 - 1620 kHz (9 kHz step)
AM (MW) Band: 520 - 1710 kHz (10 kHz step)
SW1 Band: 1711 - 10010 kHz
SW2 Band: 9990 - 20010 kHz
SW3 Band: 199901 - 29999 kHz
TUNING
AM — 10 kHz - 9 kHz
FM — 50 kHz
SENSITIVITY
FM > 5uv
MW > 0.2 mV/m
SW >20 uv
SELECTIVITY
Wide > 40 db (100x)
Narrow > 60 db (1000x)
MEMORY PRESETS
50 Total (10 Per Band)
Note: Specifications are subject to change without notice.
