3.Sub-Frequency Port
The air vent hole in the rear panel is called a Sub-Frequency Port and is designed to allow the
discharge of extreme low frequencies occurring below 60Hz.
4.Enclosure
5.Network & Power Amplifiers
Like the other components, the iM05's enclosure has an important role in shaping the overall
sonic response. In order to provide more stable performance, the iM05's enclosure employs a
special high-acoustic efficiency MDF and unique interior reinforcement designed to absorb
vibration and impact generated under extreme conditions. The custom design on the front
panel will aid in diffraction and will benefit stereo imaging.
The active crossover networks and power amplifiers for the iM05 are specially designed for this
woofer and tweeter. The network properly distributes low, mid, and high frequencies to the
driver components in order to reduce distortion and loss of sound, thus achieving a naturally
balanced sound.
In order to generate powerful, ultra-crisp sound, there are two separate power amplifiers inside
the iM05 for driving the woofer and tweeter separately in a high-end bi-amp structure. The
power delivered to the woofer driver at a low-rated distortion is 40W, and 30W is also delivered
to the tweeter.
Front and Rear Panel Features
Rear Panel Features
