PC Mode (Using the Applications)
The included CD-ROM contains a “JPEG Addin Software” application which converts
Microsoft PowerPoint data created on a PC into JPEG files and creates a
presentation folder (p. 47) for TV screen presentation (pp. 32, 33).
• Recommended for use with a 300 MHz or higher CPU (or equivalent CPU) and at least 128 MB of
memory. Also, Microsoft
®
PowerPoint
®
97/2000/2002 must be installed prior to use.
1 Turn on the PC and start Windows.
2 Load included CD-ROM into PC CD-ROM
drive.
• CD-ROM folder opens automatically. If not, open
from [My Computer].
3 In the [Setup] folder, double-click on
[Setup.exe] .
• The setup program will be executed.
• If PowerPoint has not been installed, a warning is
displayed. Click [OK], then install PowerPoint.
4 Click on [Next].
5 Confirm installation destination, then
click on [Next].
• To install into another folder, click on [Browse] and
select a folder.
6 Click on [Finish].
• If you do not want to restart the computer right
away, select “No, I will restart my computer later.”
7 Be sure CD-ROM access light is out
before removing the CD-ROM.
• This completes installation.
8 Start PowerPoint confirming that the
icon, right, is added.
Installation
• The way to open folders, shape of “Setup.exe” icon, double or single clicking, and PC messages
vary according to the PC and OS used.
– Note –
• When PC restarts, if a message, such as “Please install a JPEG filter” appears,
install “JPEG File Interchange Format Import” provided with PowerPoint.
