Syn-Tech III P25 Portable Radio
OPERATION MANUAL
680-090-2041
Version 5.0
http://www.midlandradio.com
59
8 SPECIFICATIONS
GENERAL SPECIFICATIONS
Modulation 16K0F3E, 11K0F3E, 8K0D1E, 8K0F1E
Data Rate P25 : 9.6 kb/s
Symbol Rate P25 : 4.8 kb/s
Protocol Project 25-CAI : 4.4 kb/s IMBE
Encription Algorithms DES-OFB, AES
Channel Capacity 999
Operating Voltage Range
7.5 Vdc ± % 20 (6.0-9.0 Vdc)
St-by Current Drain (backlight off)
≤ 25 mA with Power Save
≤ 65 mA without Power Save
RX Current Drain ≤ 240 mA
TX Current Drain ≤ 1700 mA
Display 64x128 pixel LCD
Keypad 18 back lit
Dimensions without battery (HxWxL) 130x58.5x17 mm (projections not included)
Weight with antenna and without battery 210 g
* Measured in the digital mode per TIA 102.CAAA under nominal conditions at 5.0 W RF output power
