Lowrance - LVR-880 Operation Instructions38
Select NEW CODE.3.
Enter the new SAME code along the dashed line, one number at a time. Press ENT to
confirm each correct entry and to move to the next digit.
If you make an error, press – until < appears, then press ENT to backup and correct the
entry.
Press ENT to store the SAME code.4.
Repeat if necessary to enter a maximum of 10 SAME codes.5.
4-8-6 Select a Working SAME code
LVR-880US only.
You must select a SAME code for your geographic working area that you have previously
entered into the radio in order to receive SAME weather alerts:
RADIO SETUP
INT SPEAKER
WATCH MODE
WX ALERT
WX ALERT
TONE ALERT
SAME ALERT
SAME CODE
SAME CODE
NEW CODE
012203
017093
012203
EDIT
DELETE CODE
SELECT CODE
SELECT CODE
012203
YES
NO
S e1. lect RADIO SETUP then WX ALERT.
Select SAME CODE. If you have already entered any SAME codes, they are listed on the 2.
LCD.
Select the SAME# for your geographic area (0122003 in the above example) and press ENT.3.
Choo4. se SELECT CODE. Then select YES.
4-9 NMEA Protocol (COM PORT)
The COM PORT must be configured correctly before use. The radio can be added to a group
of instruments using NMEA protocol.
RADIO SETUP
UNITS
INT SPEAKER
COM PORT
NMEA
CHECK SUM
ON
OFF
Select RADIO SETUP then COM PORT.1.
