Page 51
G61MP−60D−135 PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Different Blower Speeds Air Volume / Watts at Different Blower Speeds
Bottom Return Air, Side Return Air with Optional RAB
Return Air Base, Return Air from Both Sides or Return
Air from Bottom and One Side.
Single Side Return Air − Air volumes in bold require field
fabricated transition to accommodate 20 x 25 x 1 in. air
filter in order to maintain proper air velocity.
High
Medium−
High
Medium−
Low
Low High
Medium−
High
Medium−
Low
Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 2730 1465 2425 1125 2055 915 1560 680 2665 1440 2325 1100 1865 890 1410 690
0.10 2670 1440 2400 1100 2065 890 1590 675 2615 1405 2310 1065 1915 865 1465 685
0.20 2600 1400 2365 1070 2045 865 1620 665 2530 1370 2280 1055 1925 850 1570 675
0.30 2525 1360 2315 1045 2035 845 1615 655 2470 1330 2235 1015 1920 825 1590 670
0.40 2445 1325 2260 1015 2020 820 1615 645 2380 1290 2175 985 1910 805 1590 655
0.50 2360 1280 2195 985 1960 790 1610 635 2310 1265 2120 965 1890 790 1595 645
0.60 2290 1255 2130 965 1900 755 1600 615 2200 1230 2055 935 1835 765 1580 630
0.70 2205 1220 2035 910 1825 730 1570 600 2120 1190 1970 900 1790 740 1545 605
0.80 2110 1195 1945 880 1765 710 1540 580 2025 1160 1890 875 1720 710 1515 590
0.90 1970 1120 1835 830 1680 690 1540 545 1930 1110 1800 835 1655 685 1440 570
NOTES − All air data is measured external to unit without filter (not furnished − field provided).
