1. Carefully place the legs with the outside facing down, then use a 3/16” Allen wrench to loosen completely the seven screws located on the metal plate (Fig.6).

2. Press the front leg against the rear leg firmly to close the gap, then tighten the seven screws using a 3/16” Allen wrench.

3. Carefully turn the legs over so the outside is facing up, then verify that the front and rear legs are now securely fastened together (Fig.7).

1. Using a 5/32” Allen wrench, replace the four screws on the outside of the legs.

NOTE: If you are unable to tighten one of the screws, the barrel nut that secures the screw has fallen out of the underside of the stretcher bar.

The barrel nut must be installed to secure the screw.

2. Using a 3/16” Allen wrench, replace the two screws on the metal plate on the inside of the arm.

3. Replace the inner side panel then, using a 3/16” Allen wrench, replace the three screws to secure it.

4. Reinstall the pads.

TIGHTENING THE SCREWS

REINSTALLING THE LEGS

(Fig.6) (Fig.7)

Outside

facing up
