QuickSpecs
HP Compaq nx6310 Notebook PC
Technical Specifications
DA – 12432 EMEA — Version 10 — June 27, 2006 Page 20
local regulations.
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming IEEE 802.11 compliant roaming between access points
Output Power (for CKK)
2
17.5 dBm
Output Power (for OFDM;
power varies by data
rate)
2
15 dBm
Power Consumption Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode
3
: 390 mW (nominal)
Sleep mode: 20 mW (max)
Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range 802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor PCI-Express MiniCard
Weight 0.026 lb (12 g)
Dimensions 0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage 3.3v +/- 10%
Temperature Operating
Non-operating
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Choice of Configuration Utility:
• Microsoft Windows XP Wireless Network Connection Manager
• Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
LED Activity LED Off – Radio OFF; Solid LED On – Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. In Power Save Polling mode.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
5. WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN
may also be compatible with certain third-party software supplicants.
