QuickSpecs
HP Compaq nx6310 Notebook PC
Technical Specifications
DA – 12432 EMEA — Version 10 — June 27, 2006 Page 15
Width 2.75 in (70 mm)
Interface ATA-7 / SATA 1.0a
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Single Track 3 ms
Average 13 ms
Seek Time
(typical reads, including
settling)
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 156,301,488
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
Features ATA Security
Drive Weight 0.22 lb (101 g)
Capacity 60 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7 / SATA 1.0a
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Single Track 3 ms
Average 13 ms
Seek Time
(typical reads, including
settling)
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 117,231,408
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
60-GB 5400 rpm SATA
Features ATA Security
Drive Weight 0.22 lb (101 g)
Capacity 40 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7 / SATA 1.0a
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Single Track 3 ms
Average 13 ms
Seek Time
(typical reads, including
settling)
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 78,165,360
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
40-GB 5400 rpm SATA
Features ATA Security
Removable Storage Drives – Fixed Bay
Access Times Random <116 ms CDDVD-ROM Drive
<125 ms DVD
