36
Input Source Selection (Video, S-video)
Video Input
Choose Video by pressing the INPUT button on the top
control or the VIDEO button on the remote control.
Before using these buttons, correct input source should be
selected through menu operation as described below.
Press the MENU button to display the On-Screen
Menu. Press the Point ◄► buttons to move the red
frame pointer to the Input Menu icon.
Press the Point ▲▼ buttons to move the red arrow
pointer to Video and then press the SELECT button to
display the Source Select Menu .
1
2
Move the pointer to
Video and press the
SELECT button.
VIDEO
Move the pointer to the
source that you want
to select and press the
SELECT button.
Source Select Menu (VIDEO)
Input Menu
Move the pointer to the desired source and then press
the SELECT button.
3
When selecting Auto, the projector automatically
detects incoming video signal, and adjusts
itself to optimize its performance. The projector
selects connection in the following order:
1. S-video
2. Video
Auto
When video input signal is connected to the
VIDEO jack, select Video.
Video
When video input signal is connected to the
S-VIDEO jack, select S-Video.
S-video
Direct Operation
Menu Operation
Input Menu icon
REMOTE CONTROL
VIDEO button
Top Control
INPUT button
Note:
• When the Input Search function is set to “On1” or “On2”,
the input signal will be searched automatically (p.47).
Computer 1
Computer 2
VIDEO
